Detecção do movimento 2.0
Análise Humana/Veicular
4-ch
Video and Audio
Entrada de vídeo IP
16-ch
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
80 Mbps
Saída HDMI
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
Saída VGA
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Modo de saída de vídeo
HDMI/VGA simultaneous output
Saída de áudio
1-ch, RCA (Linear, 1 KO)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 k O)
Decoding
Formato de decodificação
H.265+,H.265,H.264+,H.264
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback
16-ch
Capacidade de decodificação
1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
*: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
Rede
Conexão remota
32
Protocolo de rede
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Interface de rede
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Interface Auxiliar
SATA
1 SATA interface
Capacidade
Up to 8 TB capacity for each disk
Interface USB
2 × USB 2.0
Geral
Fonte de alimentação
12 VDC, 1.5 A
Consumo
= 10 W (without HDD)
Temperatura de funcionamento
-10 °C to 55 °C (14 °F to 131 °F)
Umidade de funcionamento
10% to 90%
Dimensões (L×P×A)
320 × 240 × 48 mm (12.4" × 9.4" × 1.9")
Peso
= 1 kg (without HDD, 2.2 lb.)
